MIC200 Infrared Flammable Gas Detector

The 3-band infrared flame detector is a high quality and reliable flame detector that uses advanced flame analysis and identification technology. It responds quickly to infrared radiation in fires and has the highest immunity to false alarms. The detector contains three narrowband infrared sensors (4-6 µm) and an optical filter, which is sensitive to the CO2 emission spectrum (4.4 µm). It has a high sensitivity, which can effectively eliminate interference and achieve effective flame detection at a longer distance.

Tag: Infrared flammable detector、Open path infrared gas detector、UV flame gas detector 、Open path gas monitor、 Methane flammable gases detector、OEM/ODM infrared flammable detector

Parameter

Response spectral range	4-5um
Response time	5–10s The response time of different media is different
Viewing angle range	90 °
Detection distance	30–50 meter (depends on the burning material)
Ambient temperature	-10 ~ 55 ℃
Environmental humidity	≤95% RH
Pressure range	86 ~ 106Kpa
Working voltage	DC24V
Working current	Current≤25mA, alarm current≤35mA
Executive standard	GB15631-2008, GB3836- 2000 series
Explosion-proof grade	EXdⅡCT6
Protection grade	IP66
Signal output	4~20mA three-wire system output
Installation method	Wall or ceiling
Cable outlet thread	20mm*1.5mm free conversion G1 / 2 optional
Dimensions	19*16*11 cm
Shell material	Aluminum alloy, surface anticorrosive paint sprayed
Weight	1.7 Kg
Advantages	Dustproof, explosion-proof, corrosion-proof

Application
