Stainless Steel Fiber Bragg Grating FBG Strain Gauge Embedded type
1,520.00৳
| Place of Origin: | CN |
|---|---|
| Brand Name: | SAMYON |
| Certification: | ISO |
| Model Number: | STRAIN |
⛟ Stock products delivery time 1-3 working days. 🔥
✈ Out-of-stock products delivery time 10-20 working days. 🚀
☎️ Contact Us for any inquiry
| Product Name: | FBG Strain Gauge | Range: | ±1500με |
|---|---|---|---|
| Resolution: | ＜0.1％F.S. | Accuracy: | ＜0.3％F.S. |
| Installation: | Surface Welding / Buried | Central Wavelength: | 1525～1565nm |
| High Light: |
FBG Strain Gauge, Stainless Steel Fiber Bragg Grating, Fiber Bragg Grating FBG |
||
FBG Strain Gauge Sensor Stainless Steel Material Small Size Long Time Monitor
SAM-FBG Strain Gauge Embedded type
Description:
The Embedded FBG strain gauge is used to measure the change of strain inside concrete, it’s adopts a encapsulation structure to make the sensor itself and the concrete to achieve stiffness matching, to improve the embedding survival rate；
It is suitable for monitor the strain of long-time embedded beam, column, pile foundation, support, retaining wall, hydraulic structure, lining, pier, base and foundation.；for the temperature is compensated by embedding a strain-free cylinder.
Application:
Monitor Encapsulated structure Long-term / Short-Term Harsh Environments Monitor
Long-time Strain Monitoring of embedded beam, column, pile foundation, support, retaining wall, hydraulic structure, lining, pier, base and foundation.
Features:
●High precision, high stability, high reliability；
●Safe, anti-electromagnetic interference, corrosion resistance, pollution resistance, strong lightning resistance, can be used in strong electromagnetic interference, high lightning strike, flammable, easy explosion and other harsh conditions；
● Distance for transmission signal up to 40Km；
● Distributed measurement, multiple sensors connected on a single optical fiber (typical: 12)
● Simple layout, can be use together with other types of fiber grating sensor；
Technical specification:
| Product Name |
FBG Strain gauge
|
Temp Range |
-40℃～80℃
|
| Range |
±1500με
|
Installation |
Surface welding/ Buried
|
| Resolution |
＜0.1％F.S.
|
Sensor lead wire |
Left & Right (1m±0.1m) Armored Optical cable |
| Accuracy |
＜0.3％F.S.
|
Connection Mode |
Welding or FC/APC Joint
|
| Distance |
90mm
|
Central wavelength |
1525～1565nm
|
| Size |
Φ28×120mm
|
Reflectivity
|
＞85%
|
