Zetron PTM600-10 O2/PM2./Humidity/Temperature Online Air Quality Monitor
PTM600 portable gas detector has the function of measuring multi gases, temperature and humidity.
⛟ Stock products delivery time 1-3 working days. 🔥
✈ Out-of-stock products delivery time 10-20 working days. 🚀
☎️ Contact Us for any inquiry
Details
PTM600 portable gas detector has the function of measuring multi gases, temperature and humidity.
The product is provided with high measurement precision, stable performance and simple operation and convenient to carry. It is suitable for indoor environment of family, office, inside of cars and natural environment, etc.
It is possible to simultaneously detect 1 ~ 6 types of gases, which can be expanded to 18 or more types of gases, and the types for detection are more than 500 types.
Tag: Pump He gas monitor, Multi gas detector , Helium leak detector, Gas alarm detector, Hydrogen gas analyzer, phosphine detector, Methane leak monitor, OEM/ODM gas detector
Parameter
|
Detection factors
|
Detecting gases (standard): O2/CO2/PM2.5/PM10
|
||
|
Optional TVOC, NH3, O3 and other gases and temperature and humidity, particulate matter, differential pressure, wind speed, etc, can be expanded to detect any 30 detection factors simultaneously.
|
|||
|
Detection method
|
Built-in pump suction type, sampling distance greater than 10 meters high, flow 800ML/min, separate switch button operation switch
air pump |
||
|
Display method
|
3.5 inch 320*240 resolution large screen HD color display
|
||
|
Display content
|
Real-time concentration, alarm, time, temperature, humidity, storage, communication, power, charging status, concentration unit,
gas molecular formula, etc. |
||
|
Detection accuracy
|
≤±1% FS
|
Uncertainty
|
≤±1%
|
|
Linearity
|
≤±1%
|
Repeatability
|
≤±1%
|
|
Response time
|
T90≤20seconds
|
Recovery time
|
≤30seconds
|
|
Working power
|
DC3-5V（standard3.7VDC）
|
||
|
Battery capacity
|
10800mAH rechargeable polymer battery with overcharge, overdischarge, overvoltage, short circuit and overheat protection
|
||
|
Use environment
|
Temperature -40℃~+70℃; Relative humidity: 10-95%RH (non-condensing); Pressure: 80kPa-120kPa
|
||
|
Communication Interface
|
Standard USB charging and communication (can be customized RS485), with charging protection function, support USB hot-swapping,
support RS232 communication |
||
|
Data storage
|
Standard capacity of 100,000 (optional SD card expansion); support local view, delete or data export, storage time interval can be
set arbitrarily |
||
|
Logging
|
Record calibration log, maintenance log, failure log, sensor life expiration reminder, next concentration calibration time
reminder function. |
||
|
Interface language
|
Chinese or English can be set, default Chinese interface
|
||
|
Explosion-proof type
|
Intrinsically safe ExiaⅡCT4Ga
|
||
|
Protection level
|
IP66，Rain and water splash proof, dust proof
|
||
|
Housing material
|
Engineering plastic + 304 stainless steel + high strength, wear and corrosion resistant aluminum alloy
|
||
|
External Dimension
|
255×210×125mm(L×H×W)
|
Weight
|
2.5Kg
|
