Hight precision HF-10K Digital Force gauge Dynamometer 10000N Force Tester
1,520.00৳
⛟ Stock products delivery time 1-3 working days. 🔥
✈ Out-of-stock products delivery time 10-20 working days. 🚀
☎️ Contact Us for any inquiry
Hight precision HF-10K Digital Force gauge Dynamometer 10000N Force Tester
Product Description
The NK, NLB, ALB series are dial force gauge with compact size and high accuracy.
They are easy to operate and handy to carry out. Widely applied in rubber plastic, light industry, textile,
building windows and doors, compound materials, electric wire and cable, auto part, power generator,
scientific research institute to do the push pull force insertion force and destructive experiment.
Character
With easy operate and can be installed with all kinds of test stand and clamp.
Peak holding function and continuous.
One year free maintenance.
Compact and artistic packing, easy to transit andstock.
Two kind of unit dual show at the same time,don’t need unit conversion.
NK Series: Newton and Kilogram dual unit;
NLB Series: Newton and Pound dual unit;
ALB: Pound and Kilogram dual unit.
Needle indicates, easy to read, high accuracy
Model specification sheet of force gauge with external sensor
| Model specification | HF-2000 | HF-5000 | HF-10K | HF-20K | HF-50K | HF-100K | HF-200K | HF-500K | HF-1000K | |||
| Peak load value | 2000N | 5000N | 10KN | 20KN | 50KN | 100KN | 200KN | 500KN | 1000KN | |||
| load division value | 1N | 1N | 0.01KN | 0.01KN | 0.01KN | 0.1KN | 0.1KN | 0.1KN | 1KN | |||
| 0.1kg | 0.1kg | 0.001kg | 0.001kg | 0.001kg | 0.01kg | 0.01kg | 0.01kg | 0.1kg | ||||
| 0.1lbs | 0.1lbs | 0.001Klbs | 0.001Klbs | 0.001Klbs | 0.01Klbs | 0.01Klbs | 0.01Klbs | 0.1Klbs | ||||
| Indication error | ±1% | ±1% | ||||||||||
| Unit | N / (KN), kg / (Mg or t), lb (KIb) | |||||||||||
| Data interface | Rs232 nine-hole socket | |||||||||||
| Power | rechargeable batteries, charger(charging voltage 100V-240V) | |||||||||||
| Sensor structure | S-tye or column sensor with high precision (external sensor) | |||||||||||
| Ambient temperature | 5° C~35° C | |||||||||||
| Transport temperature | -10° C~60° C | |||||||||||
| Relative humidity | 15%~80%RH | |||||||||||
| Working conditions | No hypocenter and corrosive medium | |||||||||||
| Gross weight | 6 kg | 9 kg | 24 kg | 36 kg | ||||||||
| Size | 280 x 200 x 170 mm | 310 x 260 x 190 mm | ||||||||||
| Model specification | HF-2000K | HF-3000K |
| Peak load value | 2000KN | 3000KN |
| load division value | 1KN | |
| 0.1Mg | ||
| 0.1Klb | ||
| Indication error | ±1% | |
| Unit | N / (KN), kg / (Mg or t), lb (Klb) | |
| Data interface | Rs232 nine-hole socket | |
| Power | rechargeable batteries, charger(charging voltage 100V-240V) | |
| Sensor structure | S-type or column sensor with high precision (external sensor) | |
| Ambient temperature | 5° C~35° C | |
| Transport temperature | -10° C~60° C | |
| Relative humidity | 15%~80%RH | |
| Working conditions | No hypocenter and corrosive medium | |
| Gross weight | 36 kg | |
| Size | 310 x 260 x 190 mm | |
Product Image
