Model 200HB-3000 Brinell Hardness Tester for testing Brinell hardness of soft bearing alloys
1,520.00৳
| Place of Origin: | CN |
|---|---|
| Brand Name: | SAMYON |
| Certification: | ISO |
| Model Number: | 200HB-3000 |
⛟ Stock products delivery time 1-3 working days. 🔥
✈ Out-of-stock products delivery time 10-20 working days. 🚀
☎️ Contact Us for any inquiry
| Name: | Brinell Hardness Tester | Standard: | ISO 6506-2:2017 |
|---|---|---|---|
| Test Force: | 1838.8, 2415.8 | Measuring Range: | 8-650HBW |
| Depth Of Throat: | 150mm | Max Sample Height: | 280mm |
Model 200hb-3000 Brinell Hardness Tester
Application:
It is mainly used to determine the Brinell hardness of unquenched steel, cast iron, non-ferrous metals and soft bearing alloys, etc.
Standard:
ASTM E10-2018 Standard Test Methods for Brinell Hardness of Metallic Materials
GB/T 231.2-2012 Metallic materials – Brinell hardness test – Part 2: Verification and calibration of testing machines
ISO 6506-2:2017 Metallic materials – Brinell hardness test – Part 2: Verification and calibration of testing machines
Parameters:
| Item | Name | Details |
| 1 | Test force | 1838.8, 2415.8, 4903.5, 7355.3, 9807, 14710.5, 29421N (187.5, 250, 500, 750, 1000, 1500, 3000kgf) |
| 2 | Measuring range | 8-650HBW |
| 3 | Depth of throat | 150mm |
| 4 | Max. height of test piece | 280mm |
| 5 | Dimension | 570 x 330 x 910mm |
| 6 | Weight | approx. 220kg |
| 7 | Power | 220V AC or 110V AC, 50 or 60Hz |
Features:
1. Precision conforms to GB/T 231.2, ISO 6506-2 and ASTM E10
2. Automatic test process, no human operating error
3. Large LCD display of testing process, easy operation
4. Weight loading system
Standard accessories
Large flat anvil: 1 pc.
Small flat anvil: 1 pc.
V-notch anvil: 1 pc.
Tungsten carbide ball penetrator: Φ2.5, Φ5, Φ10mm, 1 pc. each
Brinell standardized block: 2 pcs.
20X Readout microscope: 1 pc.
Optional accessory
Rectangle work table: 400 x 150 x 30 mm
