Test tubes screw caps digital bottle cap lid torque meter ANL-P20 with printer
1,520.00৳
⛟ Stock products delivery time 1-3 working days. 🔥
✈ Out-of-stock products delivery time 10-20 working days. 🚀
☎️ Contact Us for any inquiry
ANL-P bottle lid torque tester is an intelligent and multifunction measure instrument.
Specially designed for testing and examining all kinds of bottle lid to open and close torque. Applied in examining all kinds of bottle lid,
light cap etc. open and close torque. Installed conveniently and fast, and the maximal diameter can reach 200mm,
enclosed USB serial port output, can carry out transfer the data to the computer for analysis, printing and so on related process.
Character
1:High accuracy, high stability, high resolution.
2:The sampling speed can be set.
3:The upper limit value and lower limit value can be set, has acousto-optic alarm device.
4:Lattice type liquid-crystal display, the backlight lamp can be set.
5:Torque direction identifies.
6:Three kinds of unit automatic conversion: N.m, Kg.cm, Lb.in.
7:Multi-peak values maintain.
8:Power source, electric quantity display and low electric quantity cue.
9:Close automatically under no-operation, the close time can be set.
10:Saves and prints 100 test data, delete at will.
11:Uses USB connect PC, test real-time, measure curve, and carries on processing to the data:
such as prints, statistic. and so on.
Specification
| Type
Index |
With printer | ANL-P1 | ANL-P2 | ANL-P3 | ANL-P5 | ANL-P10 | ANL-P20 |
| No printer | ANL-WP1 | ANL-WP2 | ANL-WP3 | ANL-WP5 | ANL-WP10 | ANL-WP20 | |
| Measuring range / Division value | N·m | 1.0000/0.0001 | 2.0000/0.0001 | 3.0000/
0.0001 |
5.0000/
0.0001 |
10.000/
0.001 |
20.000/
0.001 |
| Kg·cm | 10.200/
0.001 |
20.400/
0.001 |
30.600/
0.001 |
51.000/
0.001 |
102.00/
0.01 |
204.00/
0.01 |
|
| Lb·in | 8.850/
0.001 |
17.700/
0.001 |
26.550/
0.001 |
44.250/
0.001 |
88.50/
0.01 |
177.00/
0.01 |
|
| Precision | ±1% | ||||||
| Peak Value Sampling Frequency | 2000HZ | ||||||
| Power | 8.4V 1.2VX7 Ni-MH Battery group | ||||||
| Charging Time | 4-6 Hours | ||||||
| Continuous using time of battery | About 10 Hours | ||||||
| Battery life | ≥300 times | ||||||
| Size | 400mm×200mm×200mm | ||||||
| Net Weight | 12KG | ||||||
| Power adapter | Input: AC 220V 50HZ Output: DC 10V 300mA | ||||||
Note: ANL-P1 ANL-P2 ANL-P3 ANL-P5 ANL-P10 ANL-P20, they are at the same price, please leave a message which one you need.
