Wind Direction Smart Sensor
1,520.00৳
A research-grade plug-and-play sensor that provides average wind direction for the measurement interval.
⛟ Stock products delivery time 1-3 working days. 🔥
✈ Out-of-stock products delivery time 10-20 working days. 🚀
☎️ Contact Us for any inquiry
Products Description
A research-grade plug-and-play sensor that provides average wind direction for the measurement interval. This highly-durable wind vane has a drip overhang for anti-icing. Its shielded stainless-steel ball bearings and static-dissipating housing provide a long sensor life. The sensor calculates a unit vector average of the wind direction, providing data directly in degrees.
NOTE: an M-CAA Full Cross Arm or M-CAB Half Cross Arm is required for mounting.
Interested in wireless sensors? The wireless Wind Speed and Direction sensor is available for use with the HOBOnet Field Monitoring System.
Product Features
●Research-grade plug-and-play sensor for measuring and logging wind direction data
●Highly-durable wind vane has a drip overhang for anti-icing
●Shielded stainless-steel ball bearings
Product Specification
| Specifications | Wind Direction |
|---|---|
| Measurement Range | 0 to 355 degrees, 5 degree dead band |
| Maximum Wind Speed Survival | 67 m/sec (150 mph) |
| Accuracy | ± 5 degrees |
| Resolution | 1.4 degrees |
| Starting Threshold | 1.0 m/s (2.2 mph) |
| Measurement Definition | Unit vector components of wind direction are accumulated every three seconds for duration of logging interval. Average direction is calculated from the average of these. |
| Operating Temperature Range | -40°C to +70°C (-40°F to +158°F) |
| Environmental Rating | Weatherproof |
| Service Life | 4 to 6 years typical depending upon environmental conditions |
| Housing | Injection-molded housing and vane, static dissipating base, lead-free silicon bronze nose, and aluminum mounting rod. |
| Bearing Type | two shielded stainless steel ball bearings |
| Turning Radius | Approximately 13.5 cm (5.25 in.) |
| Dimensions | 46 x 20 cm (18 x 8.5 in) including 1.27 cm (0.5 in) diameter mounting rod, 2.5 mm (0.1 in) drip overhang |
| Weight | Approximately 370 g (13 oz) |
| Number of Data Channels | 1 |
| Measurement Averaging Option | Automatic averaging (see Measurement Definition) |
| Cable Length Available | 3.5 m (11.5 ft) |
| Length of Smart Sensor Network Cable | 0.5 m (1.6 ft) |
| CE | The CE Marking identifies this product as complying with all relevant directives in the European Union (EU) |
| Part Number | S-WDA-M003 |
A single HOBO Weather Station logger can accommodate 15 data channels and up to 100 m (325 ft) of smart sensor cable (the digital communications portion of the sensor cables).
